    experience with E-13 DRS on spot frame, will it fit?

    Hi,
    do any one have experience with E-13 DRS on spot frame? will it fit on the Spot Frame?
    (this spot used HL)
    Thanks In advanced!
    Last edited by gadibob; 01-07-2009 at 01:14 PM. Reason: bad spel
    Be Lucky

    Gadi.
    ----
    -------- __o
    -------_`\_<,\
    ------@/ \@
    ******************

  2. #2
    I'm more of a dog person
    Reputation: unclekittykiller's Avatar
    Join Date
    Feb 2006
    Posts
    861
    5spot doesn't have iscg tabs on bb shell. i guess you could sandwich the backer plate between the shell and bb bearing cup (assuming you are running external bearings) but the plate will move around if it is hit on a rock or something. not sure y u would need a chain guide on a spot anyway.

  3. #3
    _dw
    _dw is offline
    mtbr member
    Reputation:
    Join Date
    Jan 2004
    Posts
    1,270
    Yes, the BB mount version of the DRS fits up perfect!
    dw★link
    Split Pivot
    @daveweagle -Twitter

  4. #4
    striker!
    Reputation: superstock's Avatar
    Join Date
    Dec 2004
    Posts
    610
    Yep, you'll need to mount it behind the BB shell. It works great, I was late to the party on getting a DRS and I wished I had done it much sooner. I haven't lost my chain since!





    S

  5. #5
    Huh?
    Reputation:
    Join Date
    Apr 2005
    Posts
    819
    Yup! Ran mine that way for 3 seasons on the 04 Spot and now its on my RFX. Never once had a chain drop or any movement of the guide plate.

  6. #6
    Amphibious Technologies
    Reputation: SCUBAPRO's Avatar
    Join Date
    Jun 2004
    Posts
    3,477
    Quote Originally Posted by superstock
    It works great, I was late to the party on getting a DRS and I wished I had done it much sooner. I haven't lost my chain since!
    S
    I'm with you. The DRS is my favorite chain retention system for dual chain rings. I run them on my Spot and IH 6Point.
    "The best you've ridden is the best you know" - Paul Thede, Race Tech

  7. #7
    mtbr member
    Reputation:
    Join Date
    Mar 2006
    Posts
    60
    Thanks guys!
    what is the name / number, of the correct DRS model for the spot?
    can you say from this link?:
    http://www.chainreactioncycles.com/S...spx?Search=drs
    how is the right one?

    BTW I Use the SLX crank

    And.. if you can send sum photo of the way of how to mount it properly.. i read that its complex..

    Thanks!
    Last edited by gadibob; 01-08-2009 at 01:30 AM.
    Be Lucky

    Gadi.
    ----
    -------- __o
    -------_`\_<,\
    ------@/ \@
    ******************

  8. #8
    mtbr member
    Reputation:
    Join Date
    Mar 2006
    Posts
    60
    Quote Originally Posted by _dw
    Yes, the BB mount version of the DRS fits up perfect!
    Hi,
    whats BB mount version of the DRS, is come when you buy the DRS or should be purchase separately?

    Thanks

  9. #9
    _dw
    _dw is offline
    mtbr member
    Reputation:
    Join Date
    Jan 2004
    Posts
    1,270
    Quote Originally Posted by gadibob
    Hi,
    whats BB mount version of the DRS, is come when you buy the DRS or should be purchase separately?

    Thanks
    The BB mount version can also be mounted to ISCG-Old tabs. You can see a picture of it here: http://www.e13components.com/product_drs.html

    There is also an ISCG-05 version (not shown in the picture) that does not mount to the BB.
    dw★link
    Split Pivot
    @daveweagle -Twitter

  10. #10
    Yay! Bikes !
    Reputation: Nick.'s Avatar
    Join Date
    Dec 2003
    Posts
    1,635
    hey Dave ... any change from the current DRS for the new year?
    Nick.

  11. #11
    _dw
    _dw is offline
    mtbr member
    Reputation:
    Join Date
    Jan 2004
    Posts
    1,270
    Quote Originally Posted by Nick.
    hey Dave ... any change from the current DRS for the new year?
    No details have been released yet, but there is a new DRS+ coming. It got the same treatment as the new SRS+ and LG1+. No timeline on availability yet, we're still full bore on the existing DRS, actually our shop in Leominster, MA is assembling a DRS production run today!
    dw★link
    Split Pivot
    @daveweagle -Twitter

  12. #12
    Lay off the Levers
    Reputation: Bikezilla's Avatar
    Join Date
    Dec 2003
    Posts
    10,137
    I've had a DRS on my Spot for at least 3 years. Kickarse.
    Hey _dw has the roller changed? I loved the soft roller but the small bearings wore and seized quickly. I still run it but modded with a 'Spire wheel bolted on. I'd liked the alignment and silence of the stock design better though. The chain moved through the steps better in the stock config as well.
    Faster is better, even when it's not.
