    Before and after shots.

    I'm interested in seeing your before and after pics of trail work. Post a pic of a section of trail you've worked on before and after the work with a bit of text explaining the pics. It might be cool to have a visual library of people's trail projects. I'm looking forward to seeing other people's work.

    I'll start: This is a section of trail destroyed by Tropical Storm Leslie last year. The first pic is the day after the storm, the second was taken last week when I finally got to repairing that section. We removed the downed trees (130 in 5km of trail) last fall but the turfed up root plates left quite a hole which you can't really see in the first pic. I built a rock bridge to fill the hole and make it sensible to ride again. It's in the center of the second pic.

    EDIT: Also, if this has already been done, I apologize. I went a good ways back and didn't see a similar thread.

    Before:


    After:

  2. #2
    Delirious Tuck
    Reputation: thefriar's Avatar
    Join Date
    Jan 2008
    Posts
    2,239
    Our Hurricane Irene and Superstorm Sandy before and afters would fill a book.

  3. #3
    mtbr member
    Reputation:
    Join Date
    Feb 2006
    Posts
    587
    Quote Originally Posted by thefriar View Post
    Our Hurricane Irene and Superstorm Sandy before and afters would fill a book.
    Post a few!

  4. #4
    mtbr member
    Reputation:
    Join Date
    Feb 2006
    Posts
    587
    *crickets*

    So, no one else has any before and after pics of their trail work?

    I'll go again. This is a bridge we built over a perpetual mud hole this weekend:

    Before:





    After:





    We still need to finish armoring the entrance and exit but even now you can carry way more speed through there and into the next section. The mud hole was a real flow killer.

  5. #5
    Unpredictable
    Reputation: Ridnparadise's Avatar
    Join Date
    Dec 2007
    Posts
    1,697
    It's a good thread. If there was one in the past, then this replaces it. Now you have to give us time to dredge up pics

  6. #6
    Unpredictable
    Reputation: Ridnparadise's Avatar
    Join Date
    Dec 2007
    Posts
    1,697
    OK. Ready to play. I'll get some repairs tomorrow, but this is a before and after new trail. The last pic is taken about a year after building. The second about 6 months after.

    In the before pic there is a stump to the left of the trunks centre pic. Use it as a reference. In the last pic it has a leafy hat and is touching the tree trunk just below the top of the wound.

    The slope is circa 20-25%. The slope into the creek, like left of the tree in the last pic is 40 to 50 degrees - there's some math for you.

    Before

    Before and after shots.-p1020044.jpg

    After - the logs are to slow water flow and act as silt traps over layered rock and smaller stone. The tread has raised and become grippier over time, but you still get a splash if it is wet. This trail handles riding in the wet (even if we hate the idea of it)

    Before and after shots.-p1040781.jpg

    Now you see it, now you don't

    Before and after shots.-p1040522.jpg

  7. #7
    Delirious Tuck
    Reputation: thefriar's Avatar
    Join Date
    Jan 2008
    Posts
    2,239
    Not hurricane related... I'll dig for those, we were busy. (links not working??)

    Before:
    Trumbull Project 08-11-12

    After:
    Trumbull Project 08-11-12

  8. #8
    mtbr member
    Reputation:
    Join Date
    Aug 2011
    Posts
    59
    Before and after shots.-pict0134.jpg
    Before and after shots.-rlc5mf.jpg

    This looked pretty good, but since has been widened. Still looks good, though.

  9. #9
    mtbr member
    Reputation:
    Join Date
    Feb 2006
    Posts
    587
    Ah wow! These are exactly what I was looking for! It's super cool to see how raw woods becomes a trail.

    Thefriar: That's a hell of a bridge!

  10. #10
    mtbr member
    Reputation: Cotharyus's Avatar
    Join Date
    Jun 2012
    Posts
    1,456
    Picture size limits are a little squirrelly so you get to click links, because I can't be arsed to resize pictures.


    Before/during berm construction on a new local project:
    https://dl.dropboxusercontent.com/u/.../maplebar1.jpg

    After - not taken from exactly the same place, but it isn't hard to figure out what's going on here.
    https://dl.dropboxusercontent.com/u/.../maplebar2.jpg


    I've got a lot of pictures of stuff where there's no trail, and then there is, but most of it changes perspective, and some of it you wouldn't realize is the same spot unless you'd been there.

  11. #11
    I build my own.
    Reputation: Trail Ninja's Avatar
    Join Date
    Sep 2008
    Posts
    5,246
    Before and after shots.-018-2-.jpgBefore and after shots.-025-2-.jpg
    I have a device that can access the total knowledge of man. I use it to look at pictures of cats and argue with strangers.

  12. #12
    I build my own.
    Reputation: Trail Ninja's Avatar
    Join Date
    Sep 2008
    Posts
    5,246
    Before and after shots.-malcolm_003-2-.jpg
    Before and after shots.-malcolm_005.jpg
    Before and after shots.-malcolm_016.jpg
    Before and after shots.-malcolm_030.jpg
    I have a device that can access the total knowledge of man. I use it to look at pictures of cats and argue with strangers.

  13. #13
    I build my own.
    Reputation: Trail Ninja's Avatar
    Join Date
    Sep 2008
    Posts
    5,246
    Before and after shots.-2013-04-07-13.12.12.jpg
    Before and after shots.-2013-04-07-13.39.54.jpg
    Before and after shots.-2013-04-07-14.16.45.jpg
    I have a device that can access the total knowledge of man. I use it to look at pictures of cats and argue with strangers.

  14. #14
    I build my own.
    Reputation: Trail Ninja's Avatar
    Join Date
    Sep 2008
    Posts
    5,246
    Before and after shots.-5.jpg
    I have a device that can access the total knowledge of man. I use it to look at pictures of cats and argue with strangers.

  15. #15
    30 Czech
    Reputation: ZigaK's Avatar
    Join Date
    Sep 2009
    Posts
    16
    A large Larch fell over the path accesible by bike/foot only. Had to carry a 5kg hand winch to drag it away.



    If life gives you lemons, cry like a little girl

  16. #16
    FatBike Fiend
    Reputation: Wildfire's Avatar
    Join Date
    Feb 2004
    Posts
    870

    Before, during, and after.

    New trail project in Matanuska Greenbelt near Palmer, Alaska.
    Attached Thumbnails Attached Thumbnails Before and after shots.-bear_bottom_before_1.jpg

    Before and after shots.-bear_bottom_21.jpg

    Before and after shots.-bear_bottom_2.jpg


  17. #17
    Unpredictable
    Reputation: Ridnparadise's Avatar
    Join Date
    Dec 2007
    Posts
    1,697
    Here's one that takes a bit of explanation. When we initially flagged this area, we were intending to follow an animal (kangaroo) trail through a steep drainage slightly higher up the hill from this site. The small, orange ribbons centre of the first pic follow that line.

    Before and after shots.-p1060557.jpg

    However, that line was going to cause issues higher up the hill. In fact, about 400m farther up, it painted us into a corner where a rapid gain in altitude was required on gentle sideslope, complicated by deeper, poorly draining soil. It was all a recipe for rule-breaking and recurrent maintenance over time. So we changed our plan and went for a higher line through this location. The result was a section of trail of about 100m or so that averages 13%. We knew it would require some attention to grade and very good sightlines, being a two-way trail.

    Perspective is a strange thing. In the first pic there are 2 bent tree trunks; one to the right of the flagging and a larger one in the top, right corner. The trail now goes below the smaller one and above the one top right, making the change in grade of trail look pretty scary. Here's how things are now (before we clean the site up and finish the corner in the next pic).

    Before and after shots.-p1120368.jpg

    Before and after shots.-p1120373.jpg

    The last pic shows the 2 bent tree trunks - hard to believe the final line looking at the first pic.

    Before and after shots.-p1120364.jpg

    By the way, the jump actually controls speed because the takeoff is about 20% upslope.

  18. #18
    Unpredictable
    Reputation: Ridnparadise's Avatar
    Join Date
    Dec 2007
    Posts
    1,697
    I have to re-post this repair, because when I first posted it on MTBR, the response was it would fail as the small amount of stone alongside the trail up top would silt over and force water back on the trail etc etc. That was 16 months ago and it is better now than in any of these pics, so all good. The problem is pretty obvious - water running along trail and then into a 50cm deep erosion gully, down to a messy choke and onto a narrow trail that was held up by rotten timber and constantly under water in the wet.

    Here's the before starting at the bottom.

    Before and after shots.-p1100941.jpg

    Before and after shots.-p1050012.jpg

    Before and after shots.-p1100922.jpg

    Before and after shots.-p1050385.jpg

    Before and after shots.-p1100920.jpg

    Now the repairs (although a bit more drainage work was done past the top end)

    Before and after shots.-p1100946.jpg

    Before and after shots.-p1100960.jpg

    Before and after shots.-p1100962.jpg

    Before and after shots.-p1100952.jpg

    Before and after shots.-p1100953.jpg

  19. #19
    mtbr member
    Reputation: cmc4130's Avatar
    Join Date
    Jan 2008
    Posts
    1,317
    posted and discussed already ( Erosion-loving purists versus dirt-packing DJ/freeride rehab.... ) , but relevant to the thread.


    BEFORE:


    AFTER:

  20. #20
    I build my own.
    Reputation: Trail Ninja's Avatar
    Join Date
    Sep 2008
    Posts
    5,246
    Quote Originally Posted by cmc4130 View Post
    posted and discussed already ( Erosion-loving purists versus dirt-packing DJ/freeride rehab.... ) , but relevant to the thread.


    BEFORE:


    AFTER:
    Wait, one photo is missing. "After flash flood"
    I have a device that can access the total knowledge of man. I use it to look at pictures of cats and argue with strangers.

  21. #21
    FatBike Fiend
    Reputation: Wildfire's Avatar
    Join Date
    Feb 2004
    Posts
    870
    [QUOTE=Trail Ninja;10856538]Wait, one photo is missing. "After flash flood"[/QUOTE

    Oh...that. Great effort, anyway. Painful lessons are the best teachers.

  22. #22
    Squeaky Wheel
    Reputation:
    Join Date
    Dec 2005
    Posts
    1,851

  23. #23
    I build my own.
    Reputation: Trail Ninja's Avatar
    Join Date
    Sep 2008
    Posts
    5,246
    Quote Originally Posted by woodway View Post
    Did you find somewhere good for the water to go? How did you deal with it?
    I have a device that can access the total knowledge of man. I use it to look at pictures of cats and argue with strangers.

  24. #24
    Unpredictable
    Reputation: Ridnparadise's Avatar
    Join Date
    Dec 2007
    Posts
    1,697
    Quote Originally Posted by Trail Ninja View Post
    Did you find somewhere good for the water to go? How did you deal with it?
    I'd like to know how you got the water off too. Looks like the falline is viewer right to left. It is possible the water now drains viewers right of the ferns and then off the trail behind the photographer.

    Here's an approach we use to this problem and it is not in any way a comment on what you did, just something we have used to effect. Remove the outslope berm and drain the water. Gravel up to 2cm can now be compacted into the sodden base (fire rake will do when it is soft) until the whole thing starts to turn to jelly. Stop and come back a few days later. Repeat and maybe repeat again a couple of times until the mixture is stiff(!) and in the end the tread will be very much hardened after drying. After that it will never be wet through again as it is mostly gravel with fine silt bonded between the particles. If soil builds up over the gravel, even better, so long as it is not sand.

  25. #25
    I build my own.
    Reputation: Trail Ninja's Avatar
    Join Date
    Sep 2008
    Posts
    5,246
    I put a wooden culvert/french drain in almost the same corner but a much narrower tread, so much less water. Drained it to the inside about mid-curve and ran the water out under the tread.
    I have a device that can access the total knowledge of man. I use it to look at pictures of cats and argue with strangers.
