    Carbines SL confusion

    Need some help with Carbines without going through the whole Intense website. What is the difference between carbine and carbine SL?

    I also read G1 drop out. I think Carbine comes in 27.5 and 29 right? Or does it come in 26, and using G1, you can convert to any of those sizes? Or vice versa?

    Hopefully someone can shed some light.
    Thanks

  2. #2
    BarBanger
    Reputation:
    Join Date
    Feb 2008
    Posts
    111
    Wow. Someone is feeling lazy today. I got this info off their website. It's very easy to navigate, and quite informative.

    Carbine SL -- 26" only. Max of 5.25" travel. More XC.
    Carbine SL ? Carbon Fiber Bike Intense Cycles

    Carbine -- 26, 27.5, 29. Max of 6" travel. More AM.

    Now you know.

  3. #3
    mtbr member
    Reputation:
    Join Date
    Jun 2008
    Posts
    208
    SL is a dedicated 26er. It also has a carbon link and the frame weight comes in about half a pound lighter than the non-SL. The carbine was originally a 26er, but with ability to swap out dropouts to change it to a 27.5. Afaik, it only comes with the 27.5 dropouts now. I don't think there are any changes to the frame in the original 26" version and the 27.5 besides the dropouts, but I could have missed something somewhere.

    The best deals right now are in 26ers and the SL is a steal rig now. I have one and its a sweet frame and the ride is great. My complete weight is under 23lbs with a 1x10 setup, which I think is just incredible for a 135rr/150fr setup.
    Wanted: Ritchey P-20,21,22,23 in Team colors, 18-inch, '92-99, Ritchey Logic fork (threadless); NEW Rock Shox Judy Decal Sets

  4. #4
    mtbr member
    Reputation:
    Join Date
    May 2006
    Posts
    2,777
    The part I dont get is the G1 drop out. So 26 and 27.5 are interchangable, but definitely not 29 to 27.5 or 26 using G1 drop out right?

    yes, partially lazy on my part yesterday. But Jeff's website is kind of hard to look at on an iphone. Finally in front of a proper laptop this morning.

  5. #5
    mtbr member
    Reputation:
    Join Date
    Jun 2008
    Posts
    208
    The carbine 29 is a dedicated 29er and came out this year (2014).
    Wanted: Ritchey P-20,21,22,23 in Team colors, 18-inch, '92-99, Ritchey Logic fork (threadless); NEW Rock Shox Judy Decal Sets

  6. #6
    Dude, got any schwag?
    Reputation: TheSchwagman's Avatar
    Join Date
    Nov 2005
    Posts
    803
    I have a Carbine SL with a longer shock to get the same 5.5-6" travel as the standard Carbine. With a 150mm Revelation up front, 20mm maxle & a RWS axle in the rear, it's a 25lb sweetheart of a ride!

    To answer the OP's question, there are 3 Carbines.

    1) Std Carbine, which can be 26" or 27.5" with different G1 dropout options.
    2) Carbine SL, Which is a dedicated 26", open dropout for QR or RWS 135mm fitment. Comes stock with a shorter travel rear shock & designed for a 120mm front.
    3) Carbine 29, dedicated wagon-wheeler with G1 dropouts for adaptability to different hub standards.
    Billy

    Speed is sweet, it's like an avenue to
    ... Shredtopia!

  7. #7
    mtbr member
    Reputation:
    Join Date
    Jun 2008
    Posts
    208
    Quote Originally Posted by TheSchwagman View Post
    I have a Carbine SL with a longer shock to get the same 5.5-6" travel as the standard Carbine. With a 150mm Revelation up front, 20mm maxle & a RWS axle in the rear, it's a 25lb sweetheart of a ride!
    Schwag, could you detail exactly what shock length you put on yours? length, model, etc. I'm interested in this mod, too.

    Also, the Carbine SL shows geometry for both a 120 and 150mm fork, so I think it was designed to handle either a 120 or 150 up front.
    Wanted: Ritchey P-20,21,22,23 in Team colors, 18-inch, '92-99, Ritchey Logic fork (threadless); NEW Rock Shox Judy Decal Sets

  8. #8
    Dude, got any schwag?
    Reputation: TheSchwagman's Avatar
    Join Date
    Nov 2005
    Posts
    803
    You're correct about the bike handling a 150. The rear shock dimensions are simply the same shock as the Carbine. So 7.875" x 2.25". Still amazed by how much better this climbs than my Tracer VP did, and it corners like it's on rails! The Carbine SL's original shock was 7.5" x 2".

    Edit; And since the frame & linkage are exactly the same geometry, there are absolutely NO interference problems!
    Billy

    Speed is sweet, it's like an avenue to
    ... Shredtopia!

  9. #9
    mtbr member
    Reputation:
    Join Date
    Jun 2008
    Posts
    208
    Thanks Schwag. Hate to hijack this thread, but if I understand correctly, the 7.875" and 7.5" of the two different shocks is the eye-to-eye length, correct?

    I guess I don't understand how the longer 7.875" length shock fits onto the SL, unless it is compressed by .375" to become effectively 7.5" once installed into an SL? Or is that not how it works at all? Or does putting on a longer shock raise the BB?

    How do you know you're getting the full 150mm travel out of it?

    TIA.
    Wanted: Ritchey P-20,21,22,23 in Team colors, 18-inch, '92-99, Ritchey Logic fork (threadless); NEW Rock Shox Judy Decal Sets

  10. #10
    Dude, got any schwag?
    Reputation: TheSchwagman's Avatar
    Join Date
    Nov 2005
    Posts
    803
    Yes, these are eye to eye lengths. Trust me it fits. It'll raise the rear up a tad, but will also travel further due to the longer stroke. All you're doing is getting regular Carbine travel out of an SL. The frame and swingarm come from the same molds as the standard Carbine, and the carbon link is the exact same geometry as the aluminum link on the other bike. I calculate the travel by adding the extra 11-12% of the longer stroke shock to wheel travel. 135 + 11% = 151.
    Billy

    Speed is sweet, it's like an avenue to
    ... Shredtopia!

  11. #11
    mtbr member
    Reputation:
    Join Date
    Jun 2008
    Posts
    208
    Thanks again! Since you've ridden the SL in both the 135mm and now 150mm, how did it affect the ride or handling when you bumped up the travel? Sounds like you highly recommend this mod...do you think it voids the warranty?
    Wanted: Ritchey P-20,21,22,23 in Team colors, 18-inch, '92-99, Ritchey Logic fork (threadless); NEW Rock Shox Judy Decal Sets

  12. #12
    Dude, got any schwag?
    Reputation: TheSchwagman's Avatar
    Join Date
    Nov 2005
    Posts
    803
    Shouldn't void the warranty, but I can't make that call as a customer. ;o)

    The extra travel is always good! I can run it with a little more sag and really have it plush in mid travel without losing ANY efficiency. Rides like a dream.

    (Personal preference; I tend to run heavier damping to control wallowing during trail rides, but back off rebound and compression for Enduro style rides)
    Billy

    Speed is sweet, it's like an avenue to
    ... Shredtopia!

  13. #13
    mtbr member
    Reputation:
    Join Date
    Jun 2008
    Posts
    208
    Awesome stuff. Thanks for the tips!
    Wanted: Ritchey P-20,21,22,23 in Team colors, 18-inch, '92-99, Ritchey Logic fork (threadless); NEW Rock Shox Judy Decal Sets

  14. #14
    mtbr member
    Reputation:
    Join Date
    Jun 2008
    Posts
    208
    Quote Originally Posted by TheSchwagman View Post
    Shouldn't void the warranty, but I can't make that call as a customer. ;o)

    The extra travel is always good! I can run it with a little more sag and really have it plush in mid travel without losing ANY efficiency. Rides like a dream.

    (Personal preference; I tend to run heavier damping to control wallowing during trail rides, but back off rebound and compression for Enduro style rides)

    Can I ask what Tune shock you got? The one that came with my sl has no settings listed on it. And as a custom tune, it isn't recognized by the Fox app.
    Wanted: Ritchey P-20,21,22,23 in Team colors, 18-inch, '92-99, Ritchey Logic fork (threadless); NEW Rock Shox Judy Decal Sets

  15. #15
    Hoodbridge!
    Reputation:
    Join Date
    Aug 2012
    Posts
    14
    Resurrecting this thread, as I'm looking to possibly upgrade the rear shock. I need to know the size of the rear shock. I've seen sites saying it comes with a 7.875" x 2.25" rear shock, but in the posts above TheSchwagman says it came with 7.5" x 2" and he upgraded to a 7.875" x 2.25".

    Here's an example of a site that says it comes with 7.875" x 2.25": Intense Cycles Carbine SL Frame - Fanatik Bike Co. - Bellingham Wa

  16. #16
    I fix your broken ****!
    Reputation: Sam-IntenseCustServ's Avatar
    Join Date
    Aug 2012
    Posts
    261
    Quote Originally Posted by mav1c View Post
    Resurrecting this thread, as I'm looking to possibly upgrade the rear shock. I need to know the size of the rear shock. I've seen sites saying it comes with a 7.875" x 2.25" rear shock, but in the posts above TheSchwagman says it came with 7.5" x 2" and he upgraded to a 7.875" x 2.25".

    Here's an example of a site that says it comes with 7.875" x 2.25": Intense Cycles Carbine SL Frame - Fanatik Bike Co. - Bellingham Wa
    Direct from the source.... Carbine SL uses 7.875 x 2.0"
    Sam Wilson
    Jack of All Trades
    Intense Cycles, Inc.
    Sam@Intensecycles.com

  17. #17
    mtbr member
    Reputation: Hobine's Avatar
    Join Date
    Jun 2004
    Posts
    128

    Carbines SL confusion

    Of course Sam is correct. My stock Fox shock is a 7.875 x 50mm. I replaced it with a 7.875 x 57. Fits great with no interference.


  18. #18
    Hoodbridge!
    Reputation:
    Join Date
    Aug 2012
    Posts
    14
    Quote Originally Posted by Hobine View Post
    Of course Sam is correct. My stock Fox shock is a 7.875 x 50mm. I replaced it with a 7.875 x 57. Fits great with no interference.

    Do you run the XV or LV version?

  19. #19
    whatever she says gueuze.
    Reputation: ndinh's Avatar
    Join Date
    Mar 2004
    Posts
    345
    My setup is similar to hobine. I ride a SL with a longer stroke CCDB inline 7.875x2.25 (instead of 2.0). Fits perfectly and will get you around 150mm of travel just like the standard carbine.

  20. #20
    Hoodbridge!
    Reputation:
    Join Date
    Aug 2012
    Posts
    14
    Quote Originally Posted by ndinh View Post
    My setup is similar to hobine. I ride a SL with a longer stroke CCDB inline 7.875x2.25 (instead of 2.0). Fits perfectly and will get you around 150mm of travel just like the standard carbine.
    How much tuning did you need to do with the CCDB shock? I have to admit I'm more of a "set it and forget" guy. Is that something that can be done with the CCDB or does it require constant tuning/fiddling? Would a Fox Float CTD or RockShox Monarch RT3 be better?

  21. #21
    whatever she says gueuze.
    Reputation: ndinh's Avatar
    Join Date
    Mar 2004
    Posts
    345
    Hey mav1c,
    I'm the same way. I'm not one to fiddle with stuff once it's set. I just used Cane Creeks base tune for the initial setting:
    Base Tunes
    Afterwards, I just adjusted HSR and LSC to my trail/riding. I've never been an expert at tuning these things so I'm probably not getting the best possible performance out of it. The frame came with a CTD and I wasn't happy with it. I have a Debonair Plus on my other frame (Mojo) and it's a little more plush (also a bit longer travel) than the CCDB inline but the suspension is also different so it's like comparing apples to oranges. I can tell you that the Debonair Plus is, IMO, one of the better air shocks I've used (compared to BOS, DHX, CCDB air).
