    head tube problem

    Hi everyone, i just built my first frame. but after filleting down tube to the head tube, i noticed the the tubes were over cooked. so the tip of the head tube got deformed. then i reamed it but the edge is not equal. pics below.



    my worries is that the edge in front of the head tube. - original thickness- 1.17mm.
    what you guys think?
    TOA
    Last edited by Lakanoi; 04-14-2013 at 10:54 AM.

  2. #2
    Moderator Moderator
    Reputation:
    Join Date
    Jan 2004
    Posts
    4,116
    1.2mm wall head tube for a first frame is a bad idea - you probably should have done it with some nice solid 1.5 or 1.6mm stuff, much harder to distort if your heat control isn't great yet.

    That said I think you can probably safely ride the frame. Stick a headset in it and go.

    -Walt
    Waltworks Custom Bicycles
    Park City, UT USA
    www.waltworks.com
    waltworks.blogspot.com

  3. #3
    Nemophilist
    Reputation: TrailMaker's Avatar
    Join Date
    Sep 2007
    Posts
    1,726
    Hey;

    If you really would feel more comfortable, you could likely silver a couple of rings over the top and bottom without too much extra heartache. It might not be strictly necessary, but the extra peace of mind might be worth it for you.
    Most people ply the Well Trodden Path. A few seek a different way, and leave a Trail behind.
    - John Hajny, a.k.a. TrailMaker

  4. #4
    mtbr member
    Reputation: Meriwether's Avatar
    Join Date
    Jul 2007
    Posts
    366

    head tube problem

    This happened to me too. I just keep an eye out on the thin walled sections, and after almost a year I am still riding the frame. Your headset may slip fit too without a press in which case get some Loctite 680 and you're golden.

  5. #5
    650b me
    Reputation: golden boy's Avatar
    Join Date
    Oct 2008
    Posts
    1,073
    Quote Originally Posted by TrailMaker View Post
    Hey;

    If you really would feel more comfortable, you could likely silver a couple of rings over the top and bottom without too much extra heartache. It might not be strictly necessary, but the extra peace of mind might be worth it for you.
    I was going to reply "+1" but now 3 characters is the minimum. Here's my modified reply:

    "Yes"

  6. #6
    mtbr member
    Reputation:
    Join Date
    Aug 2009
    Posts
    4
    Thanks everyone for your + replies. i let it have a paint job,,,, thanks again
