    Fellow newbs, it can be done! DIY fork install upgrade

    The Backstory:
    Im relatively new to mountain biking, and biking in general. Almost 2 months ago I bought a brand new 2013 Scott Aspect 940 hard tail from a LBS. Ive been riding it non stop and put just over 200 mi on it so far. As my skills have improved, I noticed that my fork was seriously lacking. I have done a lot of reading on this forum, and its full of information if you just take the time to look for it. I have zero biking specific mechanical knowledge (only what I've learned on here), but do have above average basic mechanical skills.

    The Problem:
    The aspect comes stock with a sr suntour XCM coil spring fork. I was having a serious hard time at my local trail, coming out of a fast root section, immediately going into a turn and the front tire still bouncing . Well needless to say its hard to turn when the front tire isnt on the ground. This began my search for a better fork at an affordable price. I was seriously considering taking advantage of the $175 suntour upgrade program, but decided the hold out for a bit to see if something better came along. Info on that can be found here
    If you want to upgrade your Suntour fork

    The Solution:
    While I was looking around on ebay, I found a local ad for a slightly used 2012 Rock Shox Recon Silver TK Solo-Air 29 100mm travel fork (phew thats a long name), so I sent an inquiry to the owner. I verified the steerer tube size (1 1/8") and the axle size (9mm). Two days later Im the proud owner of a new (to me) fork, and for the price of the suntour upgrade promotion. I got busy with the install!

    I took on this task with basic tools. I started with removing the wheel, then the brake caliper, moved on to the stem and before i knew it, the suntour XCM was in my hand. Initially I noticed the weight difference. The RS has to be a pound lighter, at the very least!

    The install was very straight forward, as I just reversed my steps from dis-assembly. I did have to reference MTBR to figure out how to preload the head tube bearings, and that was that!

    I went for a little ride in around the house, and let me say that the difference is literally night and day! Im super excited to try this out on the trail tomorrow. It should be a whole different experience!
    Heres some pics

    Heres the Aspect 940, all stock.


    Wheel removed


    Brake line


    Caliper


    Star nut bolt? Not sure what its called. It preloads the headtube bearings


    Stem off, showing spacers


    Comparison


    Bottom bearing placement


    All done!


    I hope this is helpful to other newbs in the community. Thanks for looking

  2. #2
    mtbr member
    Reputation:
    Join Date
    Aug 2013
    Posts
    24
    I thought you actually were able to fix the Suntour fork. I HATE the top out "clunk" when going over bumps, rocks, small jumps. I put a funky external dampener (works ok) on mine to relieve the clunking until i figure out what fork to put on my bike and save some cash to do it.

  3. #3
    mtbr member
    Reputation:
    Join Date
    Jul 2013
    Posts
    97
    I think this is the only known solution for the suntour, lol

  4. #4
    RTM
    RTM is offline
    #1 Latex Salesman
    Reputation: RTM's Avatar
    Join Date
    Sep 2005
    Posts
    1,557

    Fellow newbs, it can be done! DIY fork install upgrade

    Nicely done!

    Hey, now that the mechanic bug has bitten, if you've got a birthday coming up, or just $25 you'd like to spend, pick up a copy of the Park Blue Book. Enjoy!
    "The bitterness of poor quality remains long after the sweetness of a low price is forgotten." - Benjamin Franklin

  5. #5
    My little friends
    Reputation: EABiker's Avatar
    Join Date
    Jun 2004
    Posts
    321
    Nice job on that upgrade! A word of caution to others though when buying used....make sure that the steerer tube on the donor bike was not shorter than you need. You can always cut off, (or add spacers), if the fork tube is too long, but if it was already cut and is too short, well...........

  6. #6
    mtbr member
    Reputation:
    Join Date
    Jul 2013
    Posts
    97
    Thanks for the kind words guys!
    Yes i forgot to mention the length of the steerer tube. Its pretty important.

    I finally got out for a ride to test out the new fork. Let me tell you, its a huge difference. I didnt know my bike could ride so well! Very much a worth wile investment for someone thats going to keep their bike awhile. Even when i eventually go full suspenson, im going to keep this one for a backup bike.
    I had to play a little bit on the air settings to get the sag i wanted. Im 165 lbs and right around 95psi worked perfect for me. This weekend im going to hit one of the more serious trails in my area, and see how it performs. Im super excited!

  7. #7
    mtbr member
    Reputation: mevadus's Avatar
    Join Date
    Oct 2009
    Posts
    139
    Your next upgrade should be a set of pedals, some studded flats or clipless. I prefer clipless, but some of the flats you can get with studs are amazing and just about as good as clipless. You will be amazed how a good pair of flats can make your ride that much better.

    Nice fork upgrade, btw. The Recon is way better than the Suntour. Nice choice.

  8. #8
    mtbr member
    Reputation:
    Join Date
    Jul 2013
    Posts
    97
    Quote Originally Posted by mevadus View Post
    Your next upgrade should be a set of pedals, some studded flats or clipless. I prefer clipless, but some of the flats you can get with studs are amazing and just about as good as clipless. You will be amazed how a good pair of flats can make your ride that much better.

    Nice fork upgrade, btw. The Recon is way better than the Suntour. Nice choice.
    Thanks, yes the recon is light years better than the suntour. Its pretty amazing how much better it is.

    I plan on getting a good set of flats next, as well as a decent saddle.

  9. #9
    mtbr member
    Reputation: Berkley's Avatar
    Join Date
    May 2007
    Posts
    3,200
    It looks like your new fork already had an appropriate crown race installed. If it had not, that's a key step worth mentioning.

  10. #10
    mtbr member
    Reputation:
    Join Date
    Jul 2013
    Posts
    97
    Quote Originally Posted by Berkley View Post
    It looks like your new fork already had an appropriate crown race installed. If it had not, that's a key step worth mentioning.
    I actually pulled it from the stock suntour fork, and it worked like a champ.

  11. #11
    mtbr member
    Reputation: Pollution Warrior's Avatar
    Join Date
    Apr 2010
    Posts
    385
    If more people did what you did bike shops would get a lot less business. Most stuff ain't that hard if you're motivated.

  12. #12
    Two Wheeled Terror
    Reputation: Kryptoroxx's Avatar
    Join Date
    Apr 2013
    Posts
    371

    Re: Fellow newbs, it can be done! DIY fork install upgrade

    Great job on the upgrade!!


    Quote Originally Posted by Pollution Warrior View Post
    If more people did what you did bike shops would get a lot less business. Most stuff ain't that hard if you're motivated.
    I do the same things upgrading my bike but what I do is go into the bike shop for him to check my work. They still get a few bucks for their beer fund and the best part is they don't do any work. He's also pretty good about teaching me how to do other things like bb's. He's the only bike shop for 40 miles or so and there is only two of them.



    Beamed from my dumbphone

  13. #13
    mtbr member
    Reputation:
    Join Date
    May 2009
    Posts
    157
    Quote Originally Posted by A DuB View Post
    I actually pulled it from the stock suntour fork, and it worked like a champ.
    I just swapped the same crappy Suntour for a Surly 1x1, and could not figure out why I still had play in the fork. Must have taken it apart a dozen times. Finally got frustrated, took it to LBS, and realized I had kept the crown race that came on the Surly instead of swapping over the one on the Suntour. Dumb mistake, totally overlooked on my part.

    Definitely a good point to remember.
